EEL 48V 16S DIY 280 Vertical DIY Battery Box Kits with JK Inverter BMS and Wheels EU Stock Pre-sale

$609.00 USD

Sale Sold out

Taxes included.

LCD version 3.2inch display

BMS type JK 48V 200A JK 48V 200A heating

Busbars M6 2 hole busbar M6 4 hole busbar

Quantity

Specification(Battery JK DIY Battery Box with wheels)

Battery Type:230/280/302/MB30/MB31 Cells
Material: Stainless Steel
Communication: CANBUS/RS485
BMS: 48V 16S 150/200A JK BMS
Nominal Voltage:51.2V
Active Balance Current:2A
Warranty:3 Years
OEM/ODM: Available
Weight:29kg
Parallel Type:up to 14 batteries

Parts List(does not come with the battery cells)

1 * Battery Case (front case,1*back Bracket)
1* JK LCD display with on/off switch
16 * Epoxy board(Between cell and the case)
2 * PCB Board(with sheet copper wires) for BMS and Cells Connection+2*matched EVA Tape
2 * Handles+4*wheels
1 * 48V 16S JK inverter BMS+2*BMS wires+adapter
1 * LCD Screen+1*LCD Screen wire+4 * Button Cap
2 * Special Battery Terminals (P+ Terminal and P- Terminal)
3* Long Flexible busbars (BMS connection)
15 * Flexible busbars (Cell connection)
16 * EVA Tape (Between cells)
Other Small Accessories

Download the software:

https://drive.google.com/drive/folders/1BdpkjrWTS8rM7Ph8gk29n09wh8JujVtX?usp=sharing

Bluetooth App(Android):

https://drive.google.com/file/d/1VkqUj50UKesQP7QZY3ZWnT9a0iyax6rt/view?usp=sharing

Pre-sale: Estimated shipping date: 8 Dec. 2024 (in 25 days)

Free shipping to

PL,CZ,SK,AT,DE,HU,BE,BG,DK,EE,FR,NL,LT,LV,LU,MC,

RO,HR,FL,ES,SI,SE,IT,GR,IE,PT

Materials

lithium ion phosphate,aluminum

Shipping & Returns

From overseas warehouse:5-7 days.

From China:30-40 working days

Warranty

3-Year Warranty

View full details

You may want to know about this

Q&A:

Q： What BMS is in the 48V battery box?

A: We use the 48V 16SJK-PB2A16S15P/JK-PB2A16S20P BMS in the box with CAN/RS485 Communications.

Q: Can I only take the battery box without BMS?

A: Yes, we can remove this price for you if you want to place the order.

Q: If I want to build a 48V server rack system, what should I choose?

A: It depends on how much capacity you want, our battery box can be stacked up to 15 sets.

Q: Can I buy the completed 48V server rack battery?

A: Sure, because our battery box does not include the cells, please leave a message to us if you want the completed battery system.

Q: How to set up the system?

A: The battery system can be connected to PC, and you can set and manage the whole system on your computer.

Q: If the cells are put in this way, will the bottom cells stand for the top cells' weight?

A: Please do not worry about that, the cells are recommended to compress with 300kgf, and the weight of cells is less than 300kgf.

Q: I have my own logo, can I print my logo in the battery pack?

A: Yes, we accept customizing the logo, but need a large amount(>10 sets), if you like a sample, welcome to contact us.

eason@eelbattery.com

Off-Grid Garage-Andy Review

16S 48V 150/200A JK Smart BMS

Our DIY battery box comes with the 16S 150/200A JK BMS, smart lithium lifepo4 battery module CANBUS/RS48 battery protection board Cell BMS and LCD monitoring system

Check the details

EEL Adjustable wheels

The wheels can stand 1000kg weight,we notice that some customers want to build a large battery system, but do not have a quality case, here we have the full metal case for DIY server rack standing battery system.

Battery Pallet
